LV reactive compensation filter module

Module products are composed by filter capacitor, filter reactor, switching switch, and fuse. The models of all components are selected through precise calculation, design, production and test. Compared with traditional cabinet, module cabinet has following advantages: larger capacity, easy to be expanded, convenient installation, compact structure, simple and nice layout; adopt connection without hole among units to improve power quality and prolong service life of electric equipments; protection measures are complete, such as overvoltage, undervoltage, over-temperature, overheating, harmonic.

● Detuning factor 7% or 14%;

● Capacity range: 12.5 ~ 100kvar;

● Rated voltage of capacitor : 480V or 525V;

● Applicable to 800mm or 1000mm width cabinet (other sizes need to be   made to order);

● Long service life;

● Low noise;

● Short switching cycle period.
